Display Products

Pixel Pitch (mm): P3.9, P5.95, P6.94
Location: Indoor/Outdoor
Panel Dimension (mxm): 0.5x0.5/0.5x1.0
Weight (kg/m²): 32
Pixel Composition: 3-in-1 RGB
LED Type: SMD 2020/3535
Brightness (cd/m²): 5,000-8,000
Viewing angle (°): 140

Refresh Rate (Hz): 1,920/3,840
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 10,000:1
Power Consumption (w/m²): 600 max./300 typ.
Operating Temperature: -10°C to 50C

Pixel Pitch (mm): P1.27, P1.58, P1.9, P2.57
Location: Indoor
Panel Dimension (mxm): 0.609x0.343
Weight (kg/m²): 47
Pixel Composition: 3-in-1 RGB
LED Type: SMD 1010/1514/2121
Brightness (cd/m²): > 1,000
Viewing angle (°): 140

Refresh Rate (Hz): 1,920/3,840
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 5,000:1
Power Consumption (w/m²): 720 max./350 typ.
Operating Temperature: -10°C to 50°C

Pixel Pitch (mm): P2.97, P3.9, P4.8, P5.2, P7.8
Location: Indoor
Panel Dimension (mxm): 0.5x0.5
Weight (kg/m²): 28
Pixel Composition: 3-in-1 RGB
LED Type: SMD 1514/2121/3528/3535
Brightness (cd/m²): > 1,000-3,500
Viewing angle (°): 140

Refresh Rate (Hz): 2,880
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 5,000:1
Power Consumption (w/m²): 600 max./300 typ.
Operating Temperature: -10°C to 50°C

Pixel Pitch (mm): P3.9, P4.8, P5.2
Location: Indoor
Panel Dimension (mxm): 0.5x0.5
Weight (kg/m²): 14
Pixel Composition: 3-in-1 RGB
LED Type: SMD 2121
Brightness (cd/m²): > 1,000
Viewing angle (°): 140

Refresh Rate (Hz): 2,880
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 5,000:1
Power Consumption (w/m²): 400 max./200 typ.
Operating Temperature: -10°C to 50°C

Pixel Pitch (mm): P1.667, P1.9, P2.5
Location: Indoor
Panel Dimension (mxm): 0.4x0.3
Weight (kg/m²): 40
Pixel Composition: 3-in-1 RGB
LED Type: SMD 1010/1514
Brightness (cd/m²): > 1,000
Viewing angle (°): 140

Refresh Rate (Hz): 1,920
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 5,000:1
Power Consumption (w/m²): 600 max./300 typ.
Operating Temperature: -10°C to 50°C

Pixel Pitch (mm): P3.75, P4, P4.6, P5, P6
Location: Indoor
Panel Dimension (mxm): 0.48x0.48
Weight (kg/m²): 37
Pixel Composition: 3-in-1 RGB
LED Type: SMD 2121/2724/3528
Brightness (cd/m²): > 1,000-1,600
Viewing angle (°): 140

Refresh Rate (Hz): 2,880
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 5,000:1
Power Consumption (w/m²): 430 max./220 typ.
Operating Temperature: -10°C to 50°C

Pixel Pitch (mm): P1.6, P1.9, P2.5, P4, P6, P8, P10
Location: Indoor/Outdoor
Panel Dimension (mxm): Customizable
Weight (kg/m²): 45
Pixel Composition: 3-in-1 RGB
LED Type: SMD 1010/1514/2121/3535
Brightness (cd/m²): 3,500-9,000
Viewing angle (°): 140

Refresh Rate (Hz): 1,920/3,840
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 10,000:1
Power Consumption (w/m²): 750 max./350 typ.
Operating Temperature: -10°C to 50°C

Pixel Pitch (mm): P3.9, P4.8, P5.2, P6.9
Location: Indoor/Outdoor
Panel Dimension (mxm): 0.5x1
Weight (kg/m²): 26
Pixel Composition: 3-in-1 RGB
LED Type: SMD 2121/3528
Brightness (cd/m²): > 1,000-1,500
Viewing angle (°): 140

Refresh Rate (Hz): 2,880
Color processing: 16-bit
Colors: 281 trillion
Grey Level: 65,536 steps
Color Temperature (°K): 3,500-12,000
Contrast Ratio: 5,000:1
Power Consumption (w/m²): 500 max./250 typ.
Operating Temperature: -10°C to 50°C
